Accessories · India
Jet nozzles, nozzle wrenches and bit breakers from the Volgaburmash catalogue for drill-bit operation, maintenance and safe handling. Whatever you run, the right accessories keep the string protected and the bit performing.
Correct nozzles maximize hydraulic horsepower at the bit; correct breakers prevent bit damage during makeup and breakout; and proper makeup tools protect the API connections that hold your bottom-hole assembly together.
Product Categories
Three core accessory groups cover the hydraulics, handling and connection care of every drill-bit run — supplied to drillers across India with genuine, factory-direct tooling.
Jet nozzles for Volgaburmash roller cone and PDC bits. Roller cone bits take side nozzles matched to bit size, with a central nozzle optional from 7½" and standard from 9½"; PDC bits have fixed ports or replaceable threaded nozzles.
Bit breakers for safe make-up and break-out of the bit at the rig floor. They sit in the rotary table and hold the bit while the string is rotated, machined to the bit profile so the cutting structure and body are not damaged.
Wrenches for the replaceable PDC nozzles, plus the catalogue's recommended make-up torque for bit thread connections.
The Difference
The smallest items on the rig floor have an outsized effect on performance, safety and the life of expensive tooling. Getting the accessories right is the cheapest insurance a drilling programme can buy.
The right nozzle size maximizes hydraulic horsepower at the bit, sharpening bottom-hole cleaning and lifting rate of penetration so each bit run delivers more footage.
A correct breaker prevents thread galling, body damage and cutter impact during makeup and breakout — and keeps the rig crew safe while heavy bits are handled at the floor.
Correct makeup torque combined with the proper thread compound keeps API connections sealed and prevents washouts that can lose a bottom-hole assembly downhole.
Quality accessories protect expensive bits from avoidable wear and handling damage, reduce non-productive downtime and lower the true cost-per-metre of a drilling programme.
How to Order
Accessories can be ordered as standalone items or bundled with a bit purchase, whichever suits your programme. For jet nozzles, specify the bore sizes you need in 32nds of an inch — for example 12/32" or 14/32" — together with the quantity required per size, since most bits take a set of three matched nozzles and operators usually carry several sizes to fine-tune hydraulics from run to run. For bit breakers, give us the bit size and the rotary-table bowl diameter so the breaker is machined to the correct profile and seats safely in your table.
For most rigs we recommend carrying a complete nozzle set in the common sizes plus a matching breaker for each bit size you run regularly. This keeps the floor stocked for both planned trips and unexpected bit changes, and it removes the delay of sourcing a single nozzle or breaker mid-campaign. The same logic applies to consumables — pin protectors, brass thread brushes and API-approved thread compound are inexpensive insurance against connection damage, so they are worth keeping on hand in quantity rather than ordering one at a time.
Nozzles are listed for the Volgaburmash roller cone and PDC range, including our tricone bits, and tungsten carbide jet nozzles are also on the Volgaburmash hard-alloy product list. We ship accessories from stock in Dubai, with the lead time to India confirmed with every quote. Send us your bit sizes and nozzle requirements and we will quote a complete, matched accessory package.
Keep Exploring
Send us your bit sizes, nozzle bore requirements and rotary-table details and the VBM India team will respond with availability, lead time and pricing on a complete, matched accessory package.
Request a QuoteIn stock in Dubai
158 pcs across 25 line items, ready to ship from our warehouse in Dubai (United Arab Emirates). Stock list updated 23 September 2026. Prices on request.
Shipping to India from Dubai by air or sea freight. Exact lead time is confirmed with every quote.
| Model | Size | IADC | Application | Available | Quote |
|---|---|---|---|---|---|
| TCNP525Ksection | 5 1/2" (139.7 mm) | 525X | Borewells, construction, HDD | 9 pcs | Quote |
| Bit breaker 142.9 mm | 5 5/8" (142.9 mm) | — | Bit make-up / break-out | 19 pcs | Quote |
| TCNP545Ksection | 5 5/8" (142.9 mm) | 545X | Borewells, construction, HDD | 4 pcs | Quote |
| TCNP525section | 6 1/2" (165.1 mm) | 525X | Borewells, construction, HDD | 9 pcs | Quote |
| MTR537section | 7 7/8" (200 mm) | 537X | Oil & gas | 9 pcs | Quote |
| RS617section set | 7 7/8" (200 mm) | — | Hole openers | 2 pcs | Quote |
| TCNP525section set | 7 7/8" (200 mm) | 525X | Borewells, construction, HDD | 2 pcs | Quote |
| RS615section set | 8 3/4" (222.3 mm) | — | Hole openers | 2 pcs | Quote |
| MTR535section | 12 1/4" (311.1 mm) | — | Oil & gas | 3 pcs | Quote |
| RS537section | 12 1/4" (311.1 mm) | — | Hole openers | 29 pcs | Quote |
| Bit breaker 444.5 mm | 17 1/2" (444.5 mm) | — | Bit make-up / break-out | 22 pcs | Quote |
| GRDP535section | 17 1/2" (444.5 mm) | 535X | Oil & gas | 5 pcs | Quote |
| Bit breaker 555 mm | 555 mm | — | Bit make-up / break-out | 18 pcs | Quote |
| Bit breaker 555 A mm | 555 mm | — | Bit make-up / break-out | 4 pcs | Quote |
| Bit breaker 609.6 A mm | 24" (609.6 mm) | — | Bit make-up / break-out | 8 pcs | Quote |
Showing the 15 line items with the most units out of 25. “—” under IADC: code not confirmed in the catalogue for that model (datasheet on request).
Request a Quote
Tell us your hole size, formation and IADC requirements and the VBM India team will respond with availability, lead time and pricing on the Volgaburmash range.
